Hello World Issue 4: Professional Development

Another new year brings with it thoughts of setting goals and targets. Thankfully, there is a new issue of Hello World packed with practical advise to set you on the road to success.

Hello World is our magazine about computing and digital making for educators, and it’s a collaboration between the Raspberry Pi Foundation and Computing at School, which is part of the British Computing Society.

Hello World 4 Professional Development Raspberry Pi CAS

In issue 4, our international panel of educators and experts recommends approaches to continuing professional development in computer science education.

Approaches to professional development, and much more

With recommendations for more professional development in the Royal Society’s report, and government funding to support this, our cover feature explores some successful approaches. In addition, the issue is packed with other great resources, guides, features, and lesson plans to support educators.

Highlights include:

  • The Royal Society: After the Reboot — learn about the latest report and its findings about computing education
  • The Cyber Games — a new programme looking for the next generation of security experts
  • Engaging Students with Drones
  • Digital Literacy: Lost in Translation?
  • Object-oriented Coding with Python

Get your copy of Hello World 4

Hello World is available as a free Creative Commons download for anyone around the world who is interested in computer science and digital making education. You can get the latest issue as a PDF file straight from the Hello World website.

Thanks to the very generous sponsorship of BT, we are able to offer free print copies of the magazine to serving educators in the UK. It’s for teachers, Code Club volunteers, teaching assistants, teacher trainers, and others who help children and young people learn about computing and digital making. So remember to subscribe to have your free print magazine posted directly to your home — 6000 educators have already signed up to receive theirs!

Could you write for Hello World?

By sharing your knowledge and experience of working with young people to learn about computing, computer science, and digital making in Hello World, you will help inspire others to get involved. You will also help bring the power of digital making to more and more educators and learners.

The computing education community is full of people who lend their experience to help colleagues. Contributing to Hello World is a great way to take an active part in this supportive community, and you’ll be adding to a body of free, open-source learning resources that are available for anyone to use, adapt, and share. It’s also a tremendous platform to broadcast your work: Hello World digital versions alone have been downloaded more than 50000 times!

Wherever you are in the world, get in touch with us by emailing our editorial team about your article idea.

1 Comment

Raspbery Pi-newood Derby

Andre Miron’s Pinewood Derby Instant Replay System (sorry, not sorry for the pun in the title) uses a Raspberry Pi to monitor the finishing line and play back a slow-motion instant replay, putting an end to “No, I won!” squabbles once and for all.

Raspberry Pi Based Pinewood Derby Instant Replay Demo

This is the same system I demo in this video (https://youtu.be/-QyMxKfBaAE), but on our actual track with real pinewood derby cars. Glad to report that it works great!

Pinewood Derby

For those unfamiliar with the term, the Pinewood Derby is a racing event for Cub Scouts in the USA. Cub Scouts, often with the help of a guardian, build race cars out of wood according to rules regarding weight, size, materials, etc.

Pinewood derby race car

The Cubs then race their cars in heats, with the winners advancing to district and council races.

Who won?

Andre’s Instant Replay System registers the race cars as they cross the finishing line, and it plays back slow-motion video of the crossing on a monitor. As he explains on YouTube:

The Pi is recording a constant stream of video, and when the replay is triggered, it records another half-second of video, then takes the last second and a half and saves it in slow motion (recording is done at 90 fps), before replaying.

The build also uses an attached Arduino, connected to GPIO pin 5, to trigger the recording and playback as it registers the passing cars via a voltage splitter. Additionally, the system announces the finishing places on a rather attractive-looking display above the finishing line.

Pinewood derby race car Raspberry Pi

The result? No more debate about whose car crossed the line first in neck-and-neck races.

Build your own

Andre takes us through the physical setup of the build in the video below, and you’ll find the complete code pasted in the description of the video here. Thanks, Andre!

Raspberry Pi based Pinewood Derby Instant Replay System

See the system on our actual track here: https://youtu.be/B3lcQHWGq88 Raspberry Pi based instant replay system, triggered by Arduino Pinewood Derby Timer. The Pi uses GPIO pin 5 attached to a voltage splitter on Arduino output 11 (and ground-ground) to detect when a car crosses the finish line, which triggers the replay.

Digital making in your club

If you’re a member of an various after-school association such as the Scouts or Guides, then using the Raspberry Pi and our free project resources, or visiting a Code Club or CoderDojo, are excellent ways to work towards various badges and awards. So talk to your club leader to discover all the ways in which you can incorporate digital making into your club!

2 Comments

Zero WH: pre-soldered headers and what to do with them

If you head over to the website of your favourite Raspberry Pi Approved Reseller today, you may find the new Zero WH available to purchase. But what it is? Why is it different, and what can you do with it?

Raspberry Pi Zero WH

“If you like pre-soldered headers, and getting caught in the rain…”

Raspberry Pi Zero WH

Imagine a Raspberry Pi Zero W. Now add a professionally soldered header. Boom, that’s the Raspberry Pi Zero WH! It’s your same great-tasting Pi, with a brand-new…crust? It’s perfect for everyone who doesn’t own a soldering iron or who wants the soldering legwork done for them.

What you can do with the Zero WH

What can’t you do? Am I right?! The small size of the Zero W makes it perfect for projects with minimal wiggle-room. In such projects, some people have no need for GPIO pins — they simply solder directly to the board. However, there are many instances where you do want a header on your Zero W, for example in order to easily take advantage of the GPIO expander tool for Debian Stretch on a PC or Mac.

GPIO expander in clubs and classrooms

As Ben Nuttall explains in his blog post on the topic:

[The GPIO expander tool] is a real game-changer for Raspberry Jams, Code Clubs, CoderDojos, and schools. You can live boot the Raspberry Pi Desktop OS from a USB stick, use Linux PCs, or even install [the Pi OS] on old computers. Then you have really simple access to physical computing without full Raspberry Pi setups, and with no SD cards to configure.

Using the GPIO expander with the Raspberry Pi Zero WH decreases the setup cost for anyone interested in trying out physical computing in the classroom or at home. (And once you’ve stuck your toes in, you’ll obviously fall in love and will soon find yourself with multiple Raspberry Pi models, HATs aplenty, and an area in your home dedicated to your new adventure in Raspberry Pi. Don’t say I didn’t warn you.)

Other uses for a Zero W with a header

The GPIO expander setup is just one of a multitude of uses for a Raspberry Pi Zero W with a header. You may want the header for prototyping before you commit to soldering wires directly to a board. Or you may have a temporary build in mind for your Zero W, in which case you won’t want to commit to soldering wires to the board at all.

Raspberry Pi Zero WH

Your use case may be something else entirely — tell us in the comments below how you’d utilise a pre-soldered Raspberry Pi Zero WH in your project. The best project idea will receive ten imaginary house points of absolutely no practical use, but immense emotional value. Decide amongst yourselves who you believe should win them — I’m going to go waste a few more hours playing SLUG!

37 Comments

Create SLUG! It’s just like Snake, but with a slug

Recreate Snake, the favourite mobile phone game from the late nineties, using a slug*, a Raspberry Pi, a Sense HAT, and our free resource!

Raspberry Pi Sense HAT Slug free resource

*A virtual slug. Not a real slug. Please leave the real slugs out in nature.

Snake SLUG!

Move aside, Angry Birds! On your bike, Pokémon Go! When it comes to the cream of the crop of mobile phone games, Snake holds the top spot.

Snake Nokia Game

I could while away the hours…

You may still have an old Nokia 3310 lost in the depths of a drawer somewhere — the drawer that won’t open all the way because something inside is jammed at an odd angle. So it will be far easier to grab your Pi and Sense HAT, or use the free Sense HAT emulator (online or on Raspbian), and code Snake SLUG yourself. In doing so, you can introduce the smaller residents of your household to the best reptile-focused game ever made…now with added mollusc.

The resource

To try out the game for yourself, head to our resource page, where you’ll find the online Sense HAT emulator embedded and ready to roll.

Raspberry Pi Sense HAT Slug free resource

It’ll look just like this, and you can use your computer’s arrow keys to direct your slug toward her tasty treats.

From there, you’ll be taken on a step-by-step journey from zero to SLUG glory while coding your own versionof the game in Python. On the way, you’ll learn to work with two-dimensional lists and to use the Sense HAT’s pixel display and joystick input. And by completing the resource, you’ll expand your understanding of applying abstraction and decomposition to solve more complex problems, in line with our Digital Making Curriculum.

The Sense HAT

The Raspberry Pi Sense HAT was originally designed and made as part of the Astro Pi mission in December 2015. With an 8×8 RGB LED matrix, a joystick, and a plethora of on-board sensors including an accelerometer, gyroscope, and magnetometer, it’s a great add-on for your digital making toolkit, and excellent for projects involving data collection and evaluation.

You can find more of our free Sense HAT tutorials here, including for making Flappy Bird Astronaut, a marble maze, and Pong.

No Comments

Turn your smartphone into a universal remote

Honolulu-based software developer bbtinkerer was tired of never being able to find the TV remote. So he made his own using a Raspberry Pi Zero, and connected it to a web app accessible on his smartphone.

bbtinkerer universal remote Raspberry Pi zero

Finding a remote alternative

“I needed one because the remote in my house tends to go missing a lot,” explains Bernard aka bbtinkerer on the Instructables page for his Raspberry Pi Zero Universal Remote.”If I want the controller, I have to hunt down three people and hope one of them remembers that they took it.”

bbtinkerer universal remote Raspberry Pi zero

For the build, Bernard used a Raspberry Pi Zero, an IR LED and corresponding receiver, Raspbian Lite, and a neat little 3D-printed housing.

First, he soldered a circuit for the LED and resistors on a small piece of perf board. Then he assembled the hardware components. Finally, all he needed to do was to write the code to control his devices (including a tower fan), and to set up the app.

bbtinkerer universal remote Raspberry Pi zero

Bernard employed the Linux Infrared Remote Control (LIRC) package to control the television with the Raspberry Pi Zero, accessing the Zero via SSH. He gives a complete rundown of the installation process on Instructables.

bbtinkerer universal remote Raspberry Pi zero

Setting up a remote’s buttons with LIRC is a simple case of pressing them and naming their functions one by one. You’ll need the remote to set up the system, but after that, feel free to lock it in a drawer and use your smartphone instead.

Finally, Bernard created the web interface using Node.js, and again, because he’s lovely, he published the code for anyone wanting to build their own. Thanks, Bernard!

Life hacks

If you’ve used a Raspberry Pi to build a time-saving life hack like Bernard’s, be sure to share it with us. Other favourites of ours include fridge cameras, phone app doorbell notifications, and Alan’s ocarina home automation system. I’m not sure if this last one can truly be considered a time-saving life hack. It’s still cool though!

11 Comments

Playing tic-tac-toe against a Raspberry Pi at Maker Faire

At Maker Faire New York, we met up with student Toby Goebeler of Dover High School, Pennsylvania, to learn more about his Tic-Tac-Toe Robot.

Play Tic-Tac-Toe against a Raspberry Pi #MFNYC

Uploaded by Raspberry Pi on 2017-12-18.

Tic-tac-toe with Dover Robotics

We came to see Toby and Brian Bahn, physics teacher for Dover High School and leader of the Dover Robotics club, so they could tell us about the inner workings of the Tic-Tac-Toe Robot project, and how the Raspberry Pi fit within it. Check out our video for Toby’s explanation of the build and the software controlling it.

Wooden robotic arm — Toby Goebeler Tic-Tac-Toe arm Raspberry Pi

Toby’s original robotic arm prototype used a weight to direct the pen on and off the paper. He later replaced this with a servo motor.

Toby documented the prototyping process for the robot on the Dover Robotics blog. Head over there to hear more about the highs and lows of building a robotic arm from scratch, and about how Toby learned to integrate a Raspberry Pi for both software and hardware control.

Wooden robotic arm playing tic-tac-toe — Toby Goebeler Tic-Tac-Toe arm Raspberry Pi

The finished build is a tic-tac-toe beast, besting everyone who dares to challenge it to a game.

And in case you’re wondering: no, none of the Raspberry Pi team were able to beat the Tic-Tac-Toe Robot when we played against it.

Your turn

We always love seeing Raspberry Pis being used in schools to teach coding and digital making, whether in the classroom or during after-school activities such as the Dover Robotics club and our own Code Clubs and CoderDojos. If you are part of a coding or robotics club, we’d love to hear your story! So make sure to share your experiences and projects in the comments below, or via our social media accounts.

5 Comments

I am Beemo, a little living boy: Adventure Time prop build

Bob Herzberg, BMO builder and blogger at BYOBMO.com, fills us in on the whys and hows and even the Pen Wards of creating interactive Adventure Time BMO props with the Raspberry Pi.

A Conversation With BMO

A conversation with BMO showing off some voice recognition capabilities. There is no interaction for BMO’s responses other than voice commands. There is a small microphone inside BMO (right behind the blue dot) and the voice commands are processed by Google voice API over WiFi.

Finding BMO

My first BMO began as a cosplay prop for my daughter. She and her friends are huge fans of Adventure Time and made their costumes for Princess Bubblegum, Marceline, and Finn. It was my job to come up with a BMO.

Raspberry Pi BMO Laura Herzberg Bob Herzberg

Bob as Banana Guard, daughter Laura as Princess Bubblegum, and son Steven as Finn

I wanted something electronic, and also interactive if possible. And it had to run on battery power. There was only one option that I found that would work: the Raspberry Pi.

Building a living little boy

BMO’s basic internals consist of the Raspberry Pi, an 8” HDMI monitor, and a USB battery pack. The body is made from laser-cut MDF wood, which I sanded, sealed, and painted. I added 3D-printed arms and legs along with some vinyl lettering to complete the look. There is also a small wireless keyboard that works as a remote control.

To make the front panel button function, I created a custom PCB, mounted laser-cut acrylic buttons on it, and connected it to the Pi’s IO header.

Inside BMO - Raspberry Pi BMO Laura Herzberg Bob Herzberg

Custom-made PCBs control BMO’s gaming buttons and USB input.

The USB jack is extended with another custom PCB, which gives BMO USB ports on the front panel. His battery life is an impressive 8 hours of continuous use.

The main brain game frame

Most of BMO’s personality comes from custom animations that my daughter created and that were then turned into MP4 video files. The animations are triggered by the remote keyboard. Some versions of BMO have an internal microphone, and the Google Voice API is used to translate the user’s voice and map it to an appropriate response, so it’s possible to have a conversation with BMO.

The final components of Raspberry Pi BMO Laura Herzberg Bob Herzberg

The Raspberry Pi Camera Module was also put to use. Some BMOs have a servo that can pop up a camera, called GoMO, which takes pictures. Although some people mistake it for ghost detecting equipment, BMO just likes taking nice pictures.

Who wants to play video games?

Playing games on BMO is as simple as loading one of the emulators supported by Raspbian.

BMO connected to SNES controllers - Raspberry Pi BMO Laura Herzberg Bob Herzberg

I’m partial to the Atari 800 emulator, since I used to write games for that platform when I was just starting to learn programming. The front-panel USB ports are used for connecting gamepads, or his front-panel buttons and D-Pad can be used.

Adventure time

BMO has been a lot of fun to bring to conventions. He makes it to ComicCon San Diego each year and has been as far away as DragonCon in Atlanta, where he finally got to meet the voice of BMO, Niki Yang.

BMO's back panel - Raspberry Pi BMO Laura Herzberg Bob Herzberg

BMO’s back panel, autographed by Niki Yang

One day, I received an email from the producer of Adventure Time, Kelly Crews, with a very special request. Kelly was looking for a birthday present for the show’s creator, Pendleton Ward. It was either luck or coincidence that I just was finishing up the latest version of BMO. Niki Yang added some custom greetings just for Pen.

BMO Wishes Pendleton Ward a Happy Birthday!

Happy birthday to Pendleton Ward, the creator of, well, you know what. We were asked to build Pen his very own BMO and with help from Niki Yang and the Adventure Time crew here is the result.

We added a few more items inside, including a 3D-printed heart, a medal, and a certificate which come from the famous Be More episode that explains BMO’s origins.

BMO was quite a challenge to create. Fabricating the enclosure required several different techniques and materials. Fortunately, bringing him to life was quite simple once he had a Raspberry Pi inside!

Find out more

Be sure to follow Bob’s adventures with BMO at the Build Your Own BMO blog. And if you’ve built your own prop from television or film using a Raspberry Pi, be sure to share it with us in the comments below or on our social media channels.



All images c/o Bob and Laura Herzberg

2 Comments

Why Raspberry Pi isn’t vulnerable to Spectre or Meltdown

Over the last couple of days, there has been a lot of discussion about a pair of security vulnerabilities nicknamed Spectre and Meltdown. These affect all modern Intel processors, and (in the case of Spectre) many AMD processors and ARM cores. Spectre allows an attacker to bypass software checks to read data from arbitrary locations in the current address space; Meltdown allows an attacker to read data from arbitrary locations in the operating system kernel’s address space (which should normally be inaccessible to user programs).

Both vulnerabilities exploit performance features (caching and speculative execution) common to many modern processors to leak data via a so-called side-channel attack. Happily, the Raspberry Pi isn’t susceptible to these vulnerabilities, because of the particular ARM cores that we use.

To help us understand why, here’s a little primer on some concepts in modern processor design. We’ll illustrate these concepts using simple programs in Python syntax like this one:

t = a+b
u = c+d
v = e+f
w = v+g
x = h+i
y = j+k

While the processor in your computer doesn’t execute Python directly, the statements here are simple enough that they roughly correspond to a single machine instruction. We’re going to gloss over some details (notably pipelining and register renaming) which are very important to processor designers, but which aren’t necessary to understand how Spectre and Meltdown work.

For a comprehensive description of processor design, and other aspects of modern computer architecture, you can’t do better than Hennessy and Patterson’s classic Computer Architecture: A Quantitative Approach.

What is a scalar processor?

The simplest sort of modern processor executes one instruction per cycle; we call this a scalar processor. Our example above will execute in six cycles on a scalar processor.

Examples of scalar processors include the Intel 486 and the ARM1176 core used in Raspberry Pi 1 and Raspberry Pi Zero.

What is a superscalar processor?

The obvious way to make a scalar processor (or indeed any processor) run faster is to increase its clock speed. However, we soon reach limits of how fast the logic gates inside the processor can be made to run; processor designers therefore began to look for ways to do several things at once.

An in-order superscalar processor examines the incoming stream of instructions and tries to execute more than one at once, in one of several pipelines (pipes for short), subject to dependencies between the instructions. Dependencies are important: you might think that a two-way superscalar processor could just pair up (or dual-issue) the six instructions in our example like this:

t, u = a+b, c+d
v, w = e+f, v+g
x, y = h+i, j+k

But this doesn’t make sense: we have to compute v before we can compute w, so the third and fourth instructions can’t be executed at the same time. Our two-way superscalar processor won’t actually be able to find anything to pair with the third instruction, so our example will execute in four cycles:

t, u = a+b, c+d
v    = e+f                   # second pipe does nothing here
w, x = v+g, h+i
y    = j+k

Examples of superscalar processors include the Intel Pentium, and the ARM Cortex-A7 and Cortex-A53 cores used in Raspberry Pi 2 and Raspberry Pi 3 respectively. Raspberry Pi 3 has only a 33% higher clock speed than Raspberry Pi 2, but has roughly double the performance: the extra performance is partly a result of Cortex-A53’s ability to dual-issue a broader range of instructions than Cortex-A7.

What is an out-of-order processor?

Going back to our example, we can see that, although we have a dependency between v and w, we have other independent instructions later in the program that we could potentially have used to fill the empty pipe during the second cycle. An out-of-order superscalar processor has the ability to shuffle the order of incoming instructions (again subject to dependencies) in order to keep its pipes busy.

An out-of-order processor might effectively swap the definitions of w and x in our example like this:

t = a+b
u = c+d
v = e+f
x = h+i
w = v+g
y = j+k

allowing it to execute in three cycles:

t, u = a+b, c+d
v, x = e+f, h+i
w, y = v+g, j+k

Examples of out-of-order processors include the Intel Pentium 2 (and most subsequent Intel and AMD x86 processors with the exception of some Atom and Quark devices), and many recent ARM cores, including Cortex-A9, -A15, -A17, and -A57.

What is branch prediction?

Our example above is a straight-line piece of code. Real programs aren’t like this of course: they also contain both forward branches (used to implement conditional operations like if statements), and backward branches (used to implement loops). A branch may be unconditional (always taken), or conditional (taken or not, depending on a computed value); it may be direct (explicitly specifying a target address) or indirect (taking its target address from a register, memory location or the processor stack).

While fetching instructions, a processor may encounter a conditional branch which depends on a value which has yet to be computed. To avoid a stall, it must guess which instruction to fetch next: the next one in memory order (corresponding to an untaken branch), or the one at the branch target (corresponding to a taken branch). A branch predictor helps the processor make an intelligent guess about whether a branch will be taken or not. It does this by gathering statistics about how often particular branches have been taken in the past.

Modern branch predictors are extremely sophisticated, and can generate very accurate predictions. Raspberry Pi 3’s extra performance is partly a result of improvements in branch prediction between Cortex-A7 and Cortex-A53. However, by executing a crafted series of branches, an attacker can mis-train a branch predictor to make poor predictions.

What is speculation?

Reordering sequential instructions is a powerful way to recover more instruction-level parallelism, but as processors become wider (able to triple- or quadruple-issue instructions) it becomes harder to keep all those pipes busy. Modern processors have therefore grown the ability to speculate. Speculative execution lets us issue instructions which might turn out not to be required (because they may be branched over): this keeps a pipe busy (use it or lose it!), and if it turns out that the instruction isn’t executed, we can just throw the result away.

Speculatively executing unnecessary instructions (and the infrastructure required to support speculation and reordering) consumes extra energy, but in many cases this is considered a worthwhile trade-off to obtain extra single-threaded performance. The branch predictor is used to choose the most likely path through the program, maximising the chance that the speculation will pay off.

To demonstrate the benefits of speculation, let’s look at another example:

t = a+b
u = t+c
v = u+d
if v:
   w = e+f
   x = w+g
   y = x+h

Now we have dependencies from t to u to v, and from w to x to y, so a two-way out-of-order processor without speculation won’t ever be able to fill its second pipe. It spends three cycles computing t, u, and v, after which it knows whether the body of the if statement will execute, in which case it then spends three cycles computing w, x, and y. Assuming the if (implemented by a branch instruction) takes one cycle, our example takes either four cycles (if v turns out to be zero) or seven cycles (if v is non-zero).

If the branch predictor indicates that the body of the if statement is likely to execute, speculation effectively shuffles the program like this:

t = a+b
u = t+c
v = u+d
w_ = e+f
x_ = w_+g
y_ = x_+h
if v:
   w, x, y = w_, x_, y_

So we now have additional instruction level parallelism to keep our pipes busy:

t, w_ = a+b, e+f
u, x_ = t+c, w_+g
v, y_ = u+d, x_+h
if v:
   w, x, y = w_, x_, y_

Cycle counting becomes less well defined in speculative out-of-order processors, but the branch and conditional update of w, x, and y are (approximately) free, so our example executes in (approximately) three cycles.

What is a cache?

In the good old days*, the speed of processors was well matched with the speed of memory access. My BBC Micro, with its 2MHz 6502, could execute an instruction roughly every 2µs (microseconds), and had a memory cycle time of 0.25µs. Over the ensuing 35 years, processors have become very much faster, but memory only modestly so: a single Cortex-A53 in a Raspberry Pi 3 can execute an instruction roughly every 0.5ns (nanoseconds), but can take up to 100ns to access main memory.

At first glance, this sounds like a disaster: every time we access memory, we’ll end up waiting for 100ns to get the result back. In this case, this example:

a = mem[0]
b = mem[1]

would take 200ns.

However, in practice, programs tend to access memory in relatively predictable ways, exhibiting both temporal locality (if I access a location, I’m likely to access it again soon) and spatial locality (if I access a location, I’m likely to access a nearby location soon). Caching takes advantage of these properties to reduce the average cost of access to memory.

A cache is a small on-chip memory, close to the processor, which stores copies of the contents of recently used locations (and their neighbours), so that they are quickly available on subsequent accesses. With caching, the example above will execute in a little over 100ns:

a = mem[0]    # 100ns delay, copies mem[0:15] into cache
b = mem[1]    # mem[1] is in the cache

From the point of view of Spectre and Meltdown, the important point is that if you can time how long a memory access takes, you can determine whether the address you accessed was in the cache (short time) or not (long time).

What is a side channel?

From Wikipedia:

“… a side-channel attack is any attack based on information gained from the physical implementation of a cryptosystem, rather than brute force or theoretical weaknesses in the algorithms (compare cryptanalysis). For example, timing information, power consumption, electromagnetic leaks or even sound can provide an extra source of information, which can be exploited to break the system.”

Spectre and Meltdown are side-channel attacks which deduce the contents of a memory location which should not normally be accessible by using timing to observe whether another, accessible, location is present in the cache.

Putting it all together

Now let’s look at how speculation and caching combine to permit a Meltdown-like attack on our processor. Consider the following example, which is a user program that sometimes reads from an illegal (kernel) address, resulting in a fault (crash):

t = a+b
u = t+c
v = u+d
if v:
   w = kern_mem[address]   # if we get here, fault
   x = w&0x100
   y = user_mem[x]

Now, provided we can train the branch predictor to believe that v is likely to be non-zero, our out-of-order two-way superscalar processor shuffles the program like this:

t, w_ = a+b, kern_mem[address]
u, x_ = t+c, w_&0x100
v, y_ = u+d, user_mem[x_]

if v:
   # fault
   w, x, y = w_, x_, y_      # we never get here

Even though the processor always speculatively reads from the kernel address, it must defer the resulting fault until it knows that v was non-zero. On the face of it, this feels safe because either:

  • v is zero, so the result of the illegal read isn’t committed to w
  • v is non-zero, but the fault occurs before the read is committed to w

However, suppose we flush our cache before executing the code, and arrange a, b, c, and d so that v is actually zero. Now, the speculative read in the third cycle:

v, y_ = u+d, user_mem[x_]

will access either userland address 0x000 or address 0x100 depending on the eighth bit of the result of the illegal read, loading that address and its neighbours into the cache. Because v is zero, the results of the speculative instructions will be discarded, and execution will continue. If we time a subsequent access to one of those addresses, we can determine which address is in the cache. Congratulations: you’ve just read a single bit from the kernel’s address space!

The real Meltdown exploit is substantially more complex than this (notably, to avoid having to mis-train the branch predictor, the authors prefer to execute the illegal read unconditionally and handle the resulting exception), but the principle is the same. Spectre uses a similar approach to subvert software array bounds checks.

Conclusion

Modern processors go to great lengths to preserve the abstraction that they are in-order scalar machines that access memory directly, while in fact using a host of techniques including caching, instruction reordering, and speculation to deliver much higher performance than a simple processor could hope to achieve. Meltdown and Spectre are examples of what happens when we reason about security in the context of that abstraction, and then encounter minor discrepancies between the abstraction and reality.

The lack of speculation in the ARM1176, Cortex-A7, and Cortex-A53 cores used in Raspberry Pi render us immune to attacks of the sort.

* days may not be that old, or that good

161 Comments

The Raspberry Pi PiServer tool

As Simon mentioned in his recent blog post about Raspbian Stretch, we have developed a new piece of software called PiServer. Use this tool to easily set up a network of client Raspberry Pis connected to a single x86-based server via Ethernet. With PiServer, you don’t need SD cards, you can control all clients via the server, and you can add and configure user accounts — it’s ideal for the classroom, your home, or an industrial setting.

PiServer diagram

Client? Server?

Before I go into more detail, let me quickly explain some terms.

  • Server — the server is the computer that provides the file system, boot files, and password authentication to the client(s)
  • Client — a client is a computer that retrieves boot files from the server over the network, and then uses a file system the server has shared. More than one client can connect to a server, but all clients use the same file system.
  • User – a user is a username/password combination that allows someone to log into a client to access the file system on the server. Any user can log into any client with their credentials, and will always see the same server and share the same file system. Users do not have sudo capability on a client, meaning they cannot make significant changes to the file system and software.

I see no SD cards

Last year we described how the Raspberry Pi 3 Model B can be booted without an SD card over an Ethernet network from another computer (the server). This is called network booting or PXE (pronounced ‘pixie’) booting.

Why would you want to do this?

  • A client computer (the Raspberry Pi) doesn’t need any permanent storage (an SD card) to boot.
  • You can network a large number of clients to one server, and all clients are exactly the same. If you log into one of the clients, you will see the same file system as if you logged into any other client.
  • The server can be run on an x86 system, which means you get to take advantage of the performance, network, and disk speed on the server.

Sounds great, right? Of course, for the less technical, creating such a network is very difficult. For example, there’s setting up all the required DHCP and TFTP servers, and making sure they behave nicely with the rest of the network. If you get this wrong, you can break your entire network.

PiServer to the rescue

To make network booting easy, I thought it would be nice to develop an application which did everything for you. Let me introduce: PiServer!

PiServer has the following functionalities:

  • It automatically detects Raspberry Pis trying to network boot, so you don’t have to work out their Ethernet addresses.
  • It sets up a DHCP server — the thing inside the router that gives all network devices an IP address — either in proxy mode or in full IP mode. No matter the mode, the DHCP server will only reply to the Raspberry Pis you have specified, which is important for network safety.
  • It creates usernames and passwords for the server. This is great for a classroom full of Pis: just set up all the users beforehand, and everyone gets to log in with their passwords and keep all their work in a central place. Moreover, users cannot change the software, so educators have control over which programs their learners can use.
  • It uses a slightly altered Raspbian build which allows separation of temporary spaces, doesn’t have the default ‘pi’ user, and has LDAP enabled for log-in.

What can I do with PiServer?

Serve a whole classroom of Pis

In a classroom, PiServer allows all files for lessons or projects to be stored on a central x86-based computer. Each user can have their own account, and any files they create are also stored on the server. Moreover, the networked Pis doesn’t need to be connected to the internet. The teacher has centralised control over all Pis, and all Pis are user-agnostic, meaning there’s no need to match a person with a computer or an SD card.

Build a home server

PiServer could be used in the home to serve file systems for all Raspberry Pis around the house — either a single common Raspbian file system for all Pis or a different operating system for each. Hopefully, our extensive OS suppliers will provide suitable build files in future.

Use it as a controller for networked Pis

In an industrial scenario, it is possible to use PiServer to develop a network of Raspberry Pis (maybe even using Power over Ethernet (PoE)) such that the control software for each Pi is stored remotely on a server. This enables easy remote control and provisioning of the Pis from a central repository.

How to use PiServer

The client machines

So that you can use a Pi as a client, you need to enable network booting on it. Power it up using an SD card with a Raspbian Lite image, and open a terminal window. Type in

echo program_usb_boot_mode=1 | sudo tee -a /boot/config.txt

and press Return. This adds the line program_usb_boot_mode=1 to the end of the config.txt file in /boot. Now power the Pi down and remove the SD card. The next time you connect the Pi to a power source, you will be able to network boot it.

The server machine

As a server, you will need an x86 computer on which you can install x86 Debian Stretch. Refer to Simon’s blog post for additional information on this. It is possible to use a Raspberry Pi to serve to the client Pis, but the file system will be slower, especially at boot time.

Make sure your server has a good amount of disk space available for the file system — in general, we recommend at least 16Gb SD cards for Raspberry Pis. The whole client file system is stored locally on the server, so the disk space requirement is fairly significant.

Next, start PiServer by clicking on the start icon and then clicking Preferences > PiServer. This will open a graphical user interface — the wizard — that will walk you through setting up your network. Skip the introduction screen, and you should see a screen looking like this:

PiServer GUI screenshot

If you’ve enabled network booting on the client Pis and they are connected to a power source, their MAC addresses will automatically appear in the table shown above. When you have added all your Pis, click Next.

PiServer GUI screenshot

On the Add users screen, you can set up users on your server. These are pairs of usernames and passwords that will be valid for logging into the client Raspberry Pis. Don’t worry, you can add more users at any point. Click Next again when you’re done.

PiServer GUI screenshot

The Add software screen allows you to select the operating system you want to run on the attached Pis. (You’ll have the option to assign an operating system to each client individually in the setting after the wizard has finished its job.) There are some automatically populated operating systems, such as Raspbian and Raspbian Lite. Hopefully, we’ll add more in due course. You can also provide your own operating system from a local file, or install it from a URL. For further information about how these operating system images are created, have a look at the scripts in /var/lib/piserver/scripts.

Once you’re done, click Next again. The wizard will then install the necessary components and the operating systems you’ve chosen. This will take a little time, so grab a coffee (or decaffeinated drink of your choice).

When the installation process is finished, PiServer is up and running — all you need to do is reboot the Pis to get them to run from the server.

Shooting troubles

If you have trouble getting clients connected to your network, there are a fewthings you can do to debug:

  1. If some clients are connecting but others are not, check whether you’ve enabled the network booting mode on the Pis that give you issues. To do that, plug an Ethernet cable into the Pi (with the SD card removed) — the LEDs on the Pi and connector should turn on. If that doesn’t happen, you’ll need to follow the instructions above to boot the Pi and edit its /boot/config.txt file.
  2. If you can’t connect to any clients, check whether your network is suitable: format an SD card, and copy bootcode.bin from /boot on a standard Raspbian image onto it. Plug the card into a client Pi, and check whether it appears as a new MAC address in the PiServer GUI. If it does, then the problem is a known issue, and you can head to our forums to ask for advice about it (the network booting code has a couple of problems which we’re already aware of). For a temporary fix, you can clone the SD card on which bootcode.bin is stored for all your clients.

If neither of these things fix your problem, our forums are the place to find help — there’s a host of people there who’ve got PiServer working. If you’re sure you have identified a problem that hasn’t been addressed on the forums, or if you have a request for a functionality, then please add it to the GitHub issues.

112 Comments

A hedgehog cam or two

Here we are, hauling ourselves out of the Christmas and New Year holidays and into January proper. It’s dawning on me that I have to go back to work, even though it’s still very cold and gloomy in northern Europe, and even though my duvet is lovely and warm. I found myself envying beings that hibernate, and thinking about beings that hibernate, and searching for things to do with hedgehogs. And, well, the long and the short of it is, today’s blog post is a short meditation on the hedgehog cam.

A hedgehog in a garden, photographed in infrared light by a hedgehog cam

Success! It’s a hedgehog!
Photo by Andrew Wedgbury

Hedgehog watching

Someone called Barker has installed a Raspberry Pi–based hedgehog cam in a location with a distant view of a famous Alp, and as well as providing live views by visible and infrared light for the dedicated and the insomniac, they also make a sped-up version of the previous night’s activity available. With hedgehogs usually being in hibernation during January, you mightn’t see them in any current feed — but don’t worry! You’re guaranteed a few hedgehogs on Barker’s website, because they have also thrown in some lovely GIFs of hoggy (and foxy) divas that their camera captured in the past.

A Hedgehog eating from a bowl on a patio, captured by a hedgehog cam

Nom nom nom!
GIF by Barker’s Site

Build your own hedgehog cam

For pointers on how to replicate this kind of setup, you could do worse than turn to Andrew Wedgbury’s hedgehog cam write-up. Andrew’s Twitter feed reveals that he’s a Cambridge local, and there are hints that he was behind RealVNC’s hoggy mascot for Pi Wars 2017.

RealVNC on Twitter

Another day at the office: testing our #PiWars mascot using a @Raspberry_Pi 3, #VNC Connect and @4tronix_uk Picon Zero. Name suggestions? https://t.co/iYY3xAX9Bk

Our infrared bird box and time-lapse camera resources will also set you well on the way towards your own custom wildlife camera. For a kit that wraps everything up in a weatherproof enclosure made with love, time, and serious amounts of design and testing, take a look at Naturebytes’ wildlife cam kit.

Or, if you’re thinking that a robot mascot is more dependable than real animals for the fluffiness you need in order to start your January with something like productivity and with your soul intact, you might like to put your own spin on our robot buggy.

Happy 2018

While we’re on the subject of getting to grips with the new year, do take a look at yesterday’s blog post, in which we suggest a New Year’s project that’s different from the usual resolutions. However you tackle 2018, we wish you an excellent year of creative computing.

1 Comment
