RPi Button

Sun Feb 15, 2015 8:14 pm

What do I need to connect this button to Raspberry Pi?
gordon77
Posts: 5074
Joined: Sun Aug 05, 2012 3:12 pm

Re: RPi Button

Sun Feb 15, 2015 8:17 pm

Some wires :D

Is it just a switch, or does it have a light / led in it?
DanyBv
Posts: 5
Joined: Sun Feb 15, 2015 6:22 pm

Re: RPi Button

Sun Feb 15, 2015 8:20 pm

It doesn't have leds/lights on it.
User avatar
Laurens-wuyts
Posts: 716
Joined: Wed Aug 21, 2013 7:35 pm
Location: Belgium
Contact: Website

Re: RPi Button

Sun Feb 15, 2015 8:22 pm

You can connect it like on this website.

Laurens
gordon77
Posts: 5074
Joined: Sun Aug 05, 2012 3:12 pm

Re: RPi Button

Sun Feb 15, 2015 8:23 pm

heres an example of conbecting a switch, you need some wires and resistors
https://www.cl.cam.ac.uk/projects/raspb ... _switches/
