Raw sensor access / CSI-2 receiver peripheral

[HermannSW]

I really got a "Raspberry Pi NoIR Camera Module V2" as Christmas present, and did try two nights ago to capture register sets. The camera worked fine, but captures were completely unstable for capturing two time the same command. Did try yesterday again, same results, so I did work on frame edge detection first.

Today I tried again and wanted to get to the root cause. With unrecreatable I2C decodings for the same command I went back to the command that worked well for determining 60fps/90fps difference for v2 camera. But even that did not help.

Then I even saw Pi 2B rebooting on HDMI monitor and realized that the HDMI connection might make a difference. After removing HDMI cable things were not much better, many hundred differences. I switched back to v2 camera and saw the same unrepeatable I2C sequences for same raspivid command. Finally I removed the I2C analyzer from Salea logic analyzer software and added it newly. That made a difference, with v2 camera now two captures for same command generated identical I2C sequences.

Then I switched cameras again, connecting new v2 NoIR camera module. I had to reboot after a camera switch in order to make raspivid work. Now things are much better, although I do not get identical sequences for v2 capturing of same command captured twice. But in total 133 differences and not near 4 digit numbers:

Code: Select all

$ diff --side-by-side -W 74 <(cut -f2- -d, 1.csv) <(cut -f2- -d, 2.csv) | grep "<" | wc --lines
48
$ diff --side-by-side -W 74 <(cut -f2- -d, 1.csv) <(cut -f2- -d, 2.csv) | grep "|" | wc --lines
41
$ diff --side-by-side -W 74 <(cut -f2- -d, 1.csv) <(cut -f2- -d, 2.csv) | grep ">" | wc --lines
44
$

This was the command captured:

Code: Select all

$ raspivid -t 3000 -md 7 -fps 60 -o /dev/null -w 640 -h 480 -ex off -ss 1000

And this is side-by-side difference to look at:

Code: Select all
